Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter

Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter

LCD Display Smart Water Meter

Threaded Connectivity Prepaid Water Meter

OEM/ODM Support STS Water Meter

Lugar de origen:

Hunan, China

Nombre de la marca:

Stron

Certificación:

STS Certificate,ISO9001,ISO14001

Número de modelo:

STW36

Contacta con nosotros
Solicitar una cita
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter
Detalles del producto
Clase de protección:
IP68
Duración de la batería:
8 años
Tipo de pantalla:
LCD
Clase de precisión:
Clase C
Presión de agua:
16MPA
Modo de carga:
Mantenimientos de precios del paso
Protección contra el tinte:
Protección de campo magnético
Protocolo de comunicación:
LORA RF o Bluetooth 4.0
temperatura máxima:
50℃
Pérdida máxima de presión:
0.6 bar
Tasa de flujo de sobrecarga:
3,13 (DN15 mm), 5 (DN20 mm), 7,875 (DN25 mm)
Caudal permanente:
2,5 (DN15 mm), 4 (DN20 mm), 6,3 (DN25 mm)
Caudal mínimo:
0,025 (DN15 mm), 0,04 (DN20 mm), 0,063 (DN25 mm)
Tasa de flujo de transición:
0,04 (DN15 mm), 0,064 (DN20 mm), 0,1 (DN25 mm)
Presión de trabajo máxima:
16bar
Resaltar:

LCD Display Smart Water Meter

,

Threaded Connectivity Prepaid Water Meter

,

OEM/ODM Support STS Water Meter

Condiciones de pago y envío
Cantidad de orden mínima
100
Precio
$43-45
Productos relacionados
Un buen precio. Brass Body Lora Wireless Prepaid Water Meter with 16MPA Water Pressure and 8 Years Battery Life en línea

Brass Body Lora Wireless Prepaid Water Meter with 16MPA Water Pressure and 8 Years Battery Life

Obtenga el mejor precio
Un buen precio. DN15 Prepaid Smart Water Meter with 999999.99m³ Measurement Range Anti-Theft Keyboard Type and 165mm*190mm*260mm Size en línea

DN15 Prepaid Smart Water Meter with 999999.99m³ Measurement Range Anti-Theft Keyboard Type and 165mm*190mm*260mm Size

Obtenga el mejor precio
Un buen precio. DN25 STS Standard Prepaid Water Meter with 0℃-50℃ Temperature LCD Display and LoRa-RF Communication en línea

DN25 STS Standard Prepaid Water Meter with 0℃-50℃ Temperature LCD Display and LoRa-RF Communication

Obtenga el mejor precio
Un buen precio. Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter en línea

Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter

Obtenga el mejor precio
Contacta con nosotros
86-0731-22421066
Contacta ahora
Descripción del producto
2025 New Type High-Capacity Wireless Communication RF Lora Smart Split STS Prepaid Water Meter
This STS standard token-type prepaid water meter features IP68 waterproof rating for operation in harsh environments. Its Multi-Jet construction ensures reliable operation even in muddy water without clogging. With low pressure loss (<0.06Mpa) and maintained accuracy beyond 10 years of use, it's available in multiple configurations to meet various requirements.
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 0 Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 1 Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 2
Product Variants
Prepaid Keypad Type Plastic Water Meter
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 3 Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 4
Prepaid Keypad Type Brass Water Meter
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 5 Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 6
Prepaid Split Keypad Type Brass Water Meter+CIU
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 7 Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 8
Technical Specifications
Function Details
Prepayment STS Standard, recharge by input 20digits TOKEN
Low credit alarm Alarm value can be set by inputting corresponding TOKEN
Prepaid and post-paid switch Meter can be switch to prepaid mode or post-paid mode
Non-return valve Non-return valve inside for preventing back-flow
Anti-tamper Meter will automatically close the valve after detection of magnetic field and open cover event
Step Tariff Step Tariff can be set by inputting corresponding TOKEN
Overdraft Collection Non-Revenue gas (Overdraft) can be collected day by day or month by month
Communication The meter is available with AMI system through LORA RF or Bluetooth 4.0 on request
Information Inquiry Consumer could check the data like Credit Remain, Total Purchased and Total Credit by input the short code
Metrological Parameters
Size DN15mm 1/2" DN20mm 3/4" DN25mm 1"
Overload flow rate Q4 3.13 5 7.875
Permanent flow rate Q3 2.5 4 6.3
Transitional flow rate Q2 0.04 0.064 0.1
Minimum flow rate Q1 0.025 0.04 0.063
Ratio "R" Q3/Q1 100 100 100
Maximum working pressure 16Bar 16Bar 16Bar
Maximum pressure loss 0.6Bar 0.6Bar 0.6Bar
Maximum reading 99999 99999 99999
Max temperature 50℃ 50℃ 50℃
Error Q1≦Q≦Q2 5% 5% 5%
Error Q2≦Q≦Q4 2% 2% 2%
Vending Process
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 9
Operation Steps
  1. Login vending system
  2. Meter number registration
  3. Customer information registration
  4. Price Setting
  5. Open Account
  6. Vending/Topping up meters
  7. Get the Token
  8. Input Token to meter with keypad
  9. Recharging successfully
Vending Options
Option 1: Vending at local sales point
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 10
Option 2: Vending with third party APP/mobile payment/billing system with API
API: Application Program Interface, which is the agreement connecting the third party APP and our Stronpay vending software.
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 11
Company Profile
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 12
Hunan Stron Smart Co., Ltd, founded in 2007, is the leading supplier of smart meters in China. With 500 employees including 100 technical engineers (100 with professional titles), we are committed to being the premier intelligent product service provider.
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 13 Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 14
Stron has maintained long-term cooperation with partners from over 60 countries and regions including South Africa, Nigeria, Tanzania, Kenya, Indonesia, Myanmar, Cameroon, etc.
Certifications
Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 15 Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 16 Smart Water Meter with LCD Display Threaded Connectivity and OEM/ODM Support STS Standard Prepaid Water Meter 17
